` Appendix E: Serial Data Output
SkyView System Installation Guide - Revision K 19-7
Parameter
Start
Character
Position
Num
Chars
Range of
values /Units
Example/Notes
AP Yaw Force
50
2
00 to 80
force exerted
by the yaw
servo
00 (no force exerted)
80 (max force before slipping)
00 if not engaged or AP not
installed
See Note 1
(this field will currently be 00)
Transponder
Status
52
1
0 to 3
0=SBY, 1= GND, 2=ON, 3=ALT
X if transponder not installed or
not communicating
Transponder
Reply
53
1
0 or 1
0 = No reply in last second, 1 =
at least one reply within last
second
X if transponder not installed or
not communicating
Transponder
Ident
54
1
0 or 1
0 = not IDENT'ing, 1 = IDENT
active, as reported by
Transponder
X if transponder not installed or
not communicating
Transponder
Code
55
4
0000 to 7777
XXXX if transponder not
installed or not communicating
Checksum
59
2
00 to FF
1 byte sum of all 58 preceding
bytes in hex
CR/LF
61
2
0x0D,0x0A
Carriage Return, Linefeed
Table 64 – SkyView SYSTEM Serial Data Output Format
Note 1: Yaw axis AP does not exist at this time, but the serial output format supports it.
As an example, the following is one line of DYNON SYSTEM serial output data:
!2118132412302+00101590+0500020050+16XXX30L00U02R000001110E6
