` Appendix E: Serial Data Output
SkyView System Installation Guide - Revision K 19-9
Parameter
Start
Character
Position
Num
Chars
Pin
Range of
Values/Units
Example/Notes
Volts 1
48
3
C37 P1
000 to 360
volts*10
123 (12.3 V)
see note 2
Volts 2
51
3
C37 P2
000 to 360
volts*10
123 (12.3 V)
see note 2
Amps
54
4
C37
P24/25
-999 to 999
amps*10
+123 (12.3A) or -123
(-12.3A)
see note 2
Hobbs Time
58
5
Calculated
00000 to
99999
Hours*10
12345 (1234.5 hrs)
see note 2
Tach Time
63
5
Calculated
00000 to
99999
Hours*10
12345 (1234.5 hrs)
see note 2
Thermocouple
1
68
4
C25 P2/14
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
2
72
4
C25 P3/15
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
3
76
4
C25 P4/16
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C
see note 2
Thermocouple
4
80
4
C25 P5/17
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
5
84
4
C25 P6/18
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
6
88
4
C25 P7/19
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C
see note 2
Thermocouple
7
92
4
C25 P8/20
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
8
96
4
C25 P9/21
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
9
100
4
C25
P10/22
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
