Appendix E: Serial Data Output
19-10 SkyView System Installation Guide - Revision K
Parameter
Start
Character
Position
Num
Chars
Pin
Range of
Values/Units
Example/Notes
Thermocouple
10
104
4
C25
P11/23
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C
see note 2
Thermocouple
11
108
4
C25
P12/24
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
12
112
4
C25
P13/25
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
Thermocouple
13
116
4
C37
P27/28
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C
see note 2
Thermocouple
14
120
4
C37
P36/37
-999 to 999
°C
+123 (123°C ) or -123 (-
123°C)
see note 2
GP input 1
124
6
C37 P4
Varies
see note 3
See GP output table
GP input 2
130
6
C37 P22
Varies
see note 3
See GP output table
GP input 3
136
6
C37 P23
Varies
see note 3
See GP output table
GP input 4
142
6
C37 P8
Varies
see note 3
See GP output table
GP input 5
148
6
C37 P9
Varies
see note 3
See GP output table
GP input 6
154
6
C37 P10
Varies
see note 3
See GP output table
GP input 7
160
6
C37 P11
Varies
see note 3
See GP output table
GP input 8
166
6
C37 P12
Varies
see note 3
See GP output table
GP input 9
172
6
C37 P20
Varies
see note 3
See GP output table
GP input 10
178
6
C37 P21
Varies
see note 3
See GP output table
GP input 11
184
6
C37 P6
Varies
see note 3
See GP output table
GP input 12
190
6
C37 P7
Varies
see note 3
See GP output table
