MAINTENANCE, SERVICE AND FAULT FINDING
25364 Issue 8 March 2018 4-5
Every 2 years CAUTION: The following actions
should be performed with
the printer switched off.
Check the motion of the print head for horizontal
and vertical movement. Check that movement is
smooth and free from resistance. There should be
no lateral movement from the bearings.
Inspect condition of the Carriage drive belt,
checking for signs of fraying.
Check for and remove any debris that may have
accumulated around the print head / carriage
mechanism.
Apply grease to the linear bearings (only required
if in a dusty or high temperature (35°C - 40°C)
operating environment).
Communicator II only: Check for air leaks inside
the printer, the solenoids can be activated
manually for this.
Frequency Recommended Actions
