DESCRIPTION AND INSTALLATION
2-22 25364 Issue 8 March 2018
Output Voltage
Compact 32d, 32c and 53c
Pin 9 can be used to provide 5V or 24V with ground on pins 13, 14 or 15.
Note: Default output voltage is 24V.
Output voltage of the powered contacts is set by JP1 and JP2 on the
conn
ection board, as follows:
JP1 and JP2 Position* Output Voltage (Pin 9) Maximum Current
1-2 5V 100mA
2-3 24V 500mA
*Both jumpers must be moved.
Communicator II
Pin 9 provides 5V (max 100mA) and ground is on pins 10, 13, 14 and 15
with the I/O box jumpers fitted in the default position. If the I/O box is
changed from volt free to NPN outputs then pins 11 and 12 can be used for
ground as well.
