EASYPRINT Compact 32D - Compact 32 D, 32 C and 53 C System Specification; Compact Touchscreen; Printer Specification

TECHNICAL REFERENCE
25364 Issue 8 March 2018 5-3
COMPACT 32d, 32c AND 53c SYSTEM
SPECIFICATION
Compact Touchscreen
Type 5.7 inch, full colour Compact Touchscreen
(640x480 resolution), handheld, with docking
station.
Compact Touchscreen
Dimensions (mm)
170(W) x 127.9(H) x 33.7(D)
Weight (kg) 0.385kg
Connectivity USB, Ethernet, (Mini USB for power / data
connection
to printer)
Network Interface Ethernet 10/100 base TX
Accessories Wall brackets
Operating environment 5 - 40°C
Humidity 20 - 80 % RH non-condensing
Printer Specification
Printing Mode Intermittent and Continuous
Left hand / Right hand Both options available (convertible with no
ex
tra parts in 15 minutes)
Print resolution 300 DPI
Maximum print area IM 32mm/53mm x 55mm
Maximum print area CM 32mm/53mm x 500mm
Print Speed (max) IM 400mm/s
Speed Range CM 10mm/s - 750mm/s
Print repeat rate (max) 6 prints/s (with a 10mm long print)
Ribbon drive technology i-Tech Ribbon Drive with unique dancing arm
t
ension control
Max ribbon length 770m (up to 1925m effective length with
Economy mode)
