TECHNICAL REFERENCE
5-4 25364 Issue 8 March 2018
Ribbon save modes Economy mode: Variable up to 60% with no
reduction in print resolution;
Retraction mode: Less than 1mm gap
between prints;
Column mode: 15mm max printed ribbon per
print (CM), 50mm max printed ribbon per
print (IM); Stop mid print
Print features Date code format, offsets, shift codes, serial
number generation
Fonts Most TrueType fonts
Controller / hardware
interface options
No dedicated controller required. Hardware
interface options: Easyprint Compact
Touchscreen (via USB cable- hot
swappable), Shared Compact Touchscreen
(via Ethernet cable or network), PC-based
interface (via Ethernet cable or network)
Connectivity Ethernet / USB x 2 / mini USB (service)
CAUTION: The ethernet socket includes Power over Ethernet
output (PoE)
Inputs Print Go, Encoder
Outputs Error, Ready, Ribbon Low, Spare (volt-free
contacts)
Special features Master / slave, password, Fast Mode
Label creation Onboard or via EasyDesign or QuickDesign
Electrical requirements 90V - 264V AC 50/60Hz, OR 24V d.c. (+/-
2%) at 5A (if direct)
Dimensions:
Width: 218mm
Height: 160mm
Depth: Compact 32d: 148.5mm
Compact 32c: 182mm
Compact 53c: 202mm
Weight: Compact 32d: 5.6kg
Compact 32c: 6.4kg
Compact 53c: 7.3kg
Temperature
requirements
5°C to 40°C
Humidity requirements 20-80%, RH non-condensing
