DESCRIPTION AND INSTALLATION
2-46 25364 Issue 8 March 2018
Compact 32d Ribbon Threading Procedure
Capstan
Rewind
Spindle
Ribbon Guide
Roller
Unwind
Spindle
Danc-
ing Arm
Dancing
Arm
Bridge
Cover
Ribbon Threading - Compact 32d Right-hand Printer
Ribbon
Guide
Roller
(1) Rotate the quarter-turn latch anti-clockwise. Gently pull the printer’s
front cover straight out towards you to remove it.
(2) Fit the new ribbon roll on the unwind s
pindle and the empty core to
the rewind spindle.
(3) Open the dancing arms to aid ribbon threading.
