MAINTENANCE, SERVICE AND FAULT FINDING
25364 Issue 8 March 2018 4-21
To replace the capstan roller on the Compact 32c / 53c cassette:
(1) Undo the bolt contained in the caps
tan roller, using a 5mm Allen key.
Compact 32c / 53c Cassette
Capstan
Dancing
Arms
(2) Put the new roller into the base plate.
(3) Tighten the bolt with the Allen key.
