TECHNICAL REFERENCE
5-8 25364 Issue 8 March 2018
Note: For purity of supplied compressed air, Easyprint requires
compliance with Compressed air purity classes ISO 8573-1 6 3
2 : 2001.
Storage for Printer Internal 2GB SD (Secure Digital) card.
External SD card up to 2GB. No limit for
external USB.
Electrical supply 115v to 230V 50/60Hz - Fuse 4 amp T 5x20
UL
Compressed Air Inlet Min 2 bar
Compressed Air Inlet
Max
5 bar
Compressed Air
regulated
2-5 bar (according to application)
Operating Temperature
(Celsius)
5° to 40°
Ribbon length 1600 metres (up to 3500m effective length
with Economy mode)
Approvals CE
IP Rating Designed to IP44 (when print head opening is
covered)
