DESCRIPTION AND INSTALLATION
2-28 25364 Issue 8 March 2018
The output function is programmable for each output, as shown in the
following table:
Function Behaviour
Ready Contacts closed when printer is ready
and open when printing, r
eturning or not
ready (printer open, etc.)
Not Ready (Communicator
II
)
Contacts open when printer is ready and
closed when printing, returning or not
ready (printer open, etc.)
Busy Contacts closed while print head is in
printing position and open while hea
d is
not printing
Not Busy Contacts open while print head is in
printing position and close
d while head is
not printing
Ready / Printing Contacts closed when printer is ready
and pri
nting (open while returning in IM
mode)
Ready / Returning Contacts closed when printer is ready
and
returning (open while printing)
Ready / Printing / Returning Contacts closed when printer is ready
and printing /r
eturning in IM mode
Error Contacts open when an error is active
Error (inverted)
(Compact 32d, 32c and 53c)
Contacts close when an error is active
Warning Contacts open when a warning is active
Warning (inverted)
(Compact 32d, 32c and 53c)
Contacts close when a warning is active
Note: Unless ‘inverted’ is selected, contacts are open when a fault is
raise
d to allow a fault indication if the I/O cable is disconnected.
