Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
No.
Name
Description
A
Measurement
label
Displays application and generic measurement labels. Pressing
on any label will display its associated measurements on the
touch screen.
B
Measurement
groups
Displays available measurement groups. Selecting one
measurement group will show its associated measurement
items below.
C
Measurement
items
Displays all available measurement items of the selected
measurement group. Select one measurement item, and then
measuring operations are allowed on the ultrasound image.
D
Controls
Application
Measurement
When you want to perform one measurement
which is not included in current application
measurement package, pressing this button
will bring you all the application measurements
supported on this system, and then select the
desired measurement.
Exit
Exit measurement function.
Undo
Undo the last operation.
Delete Last
Delete the last measurement result.
E
Measurement
attributes
Displays the attributes of some application measurements,
such as Left, Right, Proximal, Mid, Distal, Fetus A, Fetus B,
Fetus C, Fetus D, etc. Switch these attributes by the paddle
keys. These attributes are only displayed when they are
applicable.
F
Tool Options
When one measurement supports different tools, one Tool
Option paddle key will display for switching tools.
