Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
8.2.4. Cardiac Measurements
No.
Measurement
Group
Measurement
Item
Description
Method
Section 1: B-mode Measurements
1.1
LV Simpson
A4C Dias.
Left Ventricular apical
four-chamber views at
End-diastole
Simpson (See
section 8.2.4.1)
A4C Sys.
Left Ventricular apical
four-chamber views at
End-systole
A2C Dias.
Left Ventricular apical
two-chamber views at
End-diastole
A2C Sys.
Left Ventricular apical
two-chamber views at End-systole
1.2
A/L(LV)
LVd
Left Ventricular Dimension at End
Diastole
Cir/Area in
B-mode generic
measurements
LVs
Left Ventricular Dimension at End
Systole
1.3
Simp(LA)
LA A4Cs
Left Atria Four Chamber View at
End Systole
Simpson (See
section 8.2.4.1)
LA A2Cs
Left Atria Two Chamber View at
End Systole
1.4
Simp(RA)
RA A4Cs
Right Atriaapical four-chamber
views at End-diastole
1.5
LVM(A/L)
LVAd Sax Epi
Left Ventricular Epicardial Area at
Papillary Muscle Level at End
Diastole in Short-axis View
Cir/Area in
B-mode generic
measurements
LVAd Sax Endo
Left Ventricular Endocardial Area
at Papillary Muscle Level at End
Systole in Short-axis View
LVLd Apical
Left Ventricular Long Axis Length
at End Diastole in Apical View
Distance in
B-mode generic
measurements
1.6
LV/RV
RVAWd
Right Ventricular Anterior Wall
Thickness at End-diastole
Distance in
B-mode generic
measurements
RVIDd
Right Ventricular Internal
Diameter at end-diastole
LVIDd
Left Ventricular Internal Diameter
at End-diastole
