Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Imaging
5.9.2. 3D Volume Sweeping
Select Skeleton or Surface on the Pre-3D touch screen and press Start button or <Update> key to
start image acquisition.
During the process of 3D volume sweeping, the images swept in VOI box are displayed in the image
area.
Figure 5-2 3D Image Scanning
While scanning, the sector in the right bottom is filled gradually, and no buttons on the control
panel and touch screen can be activated.
5.9.3. 3D Image Review
The system will enter to the 3D review status after finishing one sweep.
Figure 5-3 3D Image Review
