Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Ultrasound Gel Warmer
Appendix E Ultrasound Gel Warmer
Ultrasound gel warmer is intended for heating the ultrasound gel. It is installed at the left upper corner
of the control panel, as shown in the figure below.
To install gel warmer:
Put the gel warmer at the left corner of the control panel and connect the Power connector of gel
warmer to the power socket on the below of control panel, as the figure shown below:
Ultrasound Gel
Gel Warmer
Power Switch
Power connector
