Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
8.2.1. Abdomen Measurements
No.
Measurement
Group
Measurement
Item
Description
Method
Section 1: B-mode Measurements
1.1
Liver
Liver L
Liver Length
2-point distance
in B-mode
generic
measurements
Liver W
Liver Width
Liver H
Liver Height
Portal Vein
Portal Vein Diameter
CHD
Common Hepatic Duct
1.2
Gall Bladder
GB L
Gallbladder Length
GB H
Gallbladder Height
GB wall th
Gallbladder wall thickness
CBD
Common Bile Duct
1.3
Pancreas
Panc duct
Pancreatic duct
Panc head
Pancreatic head
Panc body
Pancreatic body
Panc tail
Pancreatic tail
1.4
Spleen
Spleen L
Spleen Length
Spleen H
Spleen Height
1.5
Renal
Renal L
Renal Length
Renal W
Renal Width
Renal H
Renal Height
Cortex
Renal Cortex thickness
1.6
Aorta Diam
Aorta Diameter
Section 2: Doppler Measurements
2.1
AA
PS
ED
RI
PI
PS,ED,RI,S/D
Time
HR
Auto Trace
Manual Trace
Spline Trace
Abdominal Aorta
Doppler generic
measurements
2.2
SMA
Superior Mesenteric Artery
2.3
IMA
Inferior Mesenteric Artery
2.4
HA
Hepatic Artery
2.5
Splenic A
Splenic Artery
2.6
Renal A
Renal Artery
2.7
Portal V
Portal Vein
Velocity in
Doppler generic
measurements
2.8
IVC
Inferior Vena Cava
2.9
M Portal V
Main Portal Vein
2.10
Hepatic V
Hepatic Vein
2.11
M Hepatic V
Middle Hepatic Vein
