Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Features
Deleting a body mark:
There are two ways of deleting a body mark graphic:
 Press Delete on the touch screen to delete the graphics on the image area.
 Press the <Clear> hard key to delete all body marks, comments, and measurements.
7.3 Split Display
7.3.1. Dual Imaging
Dual Imaging displays images side by side on the screen. During real-time imaging when Dual
imaging is enabled, the active image is displayed in real-time and the other image is frozen.
Dual image display is invoked by pressing Dual button on the B-mode touch screen or dual hard key
on the console. Each single press of Dual function during real-time imaging activates the
image on one side and the image on other side becomes frozen. With both images frozen, each single
press of Dual function toggles between two images, but does not change the frozen status of the
system.
In Dual mode, press Single button on the touch screen or single hard key on the console to
display the currently active side of image as a single image.
Dual Exit
Dual is exited by any of the following:
 Pressing the Quad button or Quad hard key.
 Pressing the B, M, PW, CW hard key.
 Pressing the 3D, 4D button.
 Transducer change, preset recall, or new exam.
Color Doppler is available during dual imaging.
7.3.2. Quad Imaging
Quad Imaging displays images in four quadrants on the screen. During real-time imaging when Quad
imaging is enabled, the active image is displayed in real-time and other images are frozen.
Quad imaging is invoked by pressing Quad button on the B-mode touch screen or quad hard key
on the console. Quad function button is a one-shot button. Each single press on it during
real-time imaging activates one of the four images in the following order: from top left image to top
right image, then to bottom left image and bottom right image. Each single press on it during frozen
status switches among the four images in an order described above. but does not change the frozen
status of the system.
Quad Exit
Quad is exited by any of the following:
 Pressing the B, M, PW, CW hard key.
 Pressing the Dual button or dual hard key.
 Pressing the 3D, 4D button.
 Transducer change, preset recall, or new exam.
Color Doppler is available during Quad imaging.
