Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Circumference/Area measurement.
4. Measure the normal tissue (Displayed as B=XX%) following the Ellipse method in section
8.1.1.2 Circumference/Area measurement.
5. The system automatically calculates the strain ratio between lesion (A) and normal tissue (B). It
is suggest to measure the lesion and normal tissue at the same depth.
Trace Method:
1. Invoke the generic measurement function.
2. Select Eratio-> Eratio Trace.
3. Measure the lesion (Displayed as A=XX%) following the Trace method in section 8.1.1.2
Circumference/Area measurement.
4. Measure the normal tissue (Displayed as B=XX%) following the Trace method in section
8.1.1.2 Circumference/Area measurement.
5. The system automatically calculates the strain ratio between lesion (A) and normal tissue (B). It
is suggest to measure the lesion and normal tissue at the same depth.
8.1.2. M-mode Generic Measurements
The generic measurements supported in M-mode are listed in the table below.
8.1.2.1. Distance
The distance measurement measures the distance between two points at the vertical direction. To
measure the distance:
1. Invoke the generic measurement function.
2. Select Dist. 2 Point.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.2. Slope
The Slope measurement measures the distance and time between two points, and calculates the
slope. To measure Slope:
1. Invoke the generic measurement function.
2. Select Slope.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
To Next Page
