Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.3. Time
The Time measurement measure the time interval between two points. To measure Time:
1. Invoke the generic measurement function.
2. Select Time.
3. Move the caliper to the start point.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the end point.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.2.4. HR
The HR measurement measures the time interval between two points, and calculates the heart rate.
To measure HR:
1. Invoke the generic measurement function.
2. Select HR.
3. Move the caliper to the first heartbeat.
4. Press the <Set> key to fix the start point.
5. Move the caliper to the next beat.
Presses of the <Update> key will toggle between active calipers, allowing you to adjust the
position of start point and end point.
6. Press the <Set> key to fix the end point and complete the measurement.
8.1.3. Strip Doppler Generic Measurements
The generic measurements supported in strip Doppler mode are listed in the table below.
No.
Measurement
Group
Measurement Item
Remark
1.
Generic
PS
ED
RI
PI
PS,ED,RI,S/D
Time
HR
Manual Trace
