Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Specifications
Appendix A Specifications
A.1 Electrical Safety Classifications
According to the type of protection
against electric shock
Internally powered equipment,
Class I equipment
According to the degree of protection
against electric shock
Type BF(transducer)
Type CF(ECG module)
According to the degree of protection
against harmful ingress of liquid
Whole device: IPX0
Transducer (not including the transducer connector): IPX7;
Footswitch: IP68
According to the degree of safety of
application in the presence of a
flammable gas
Equipment not suitable for use in the presence of a
flammable gas
According to the mode of operation
Continuous operation
According to the grade of EMC
CISPR 11 Group 1, Class A
Standards Compliance
EN 60601-1:2006/A1:2013
idt IEC 60601-1: 2005/A1:2012
EN 60601-1-2: 2015
idt IEC 60601-1-2: 2014
EN 60601-2-37:2018/A1:2015
idt IEC 60601-2-37:2007/A1:2015
A.2 Power Supply
Operating Voltage
100 -240 V~
Operating Frequency
50 Hz/60 Hz
AC Input Current
5.2A-2.5A
A.3 Battery
Capacity
6800 mAh *2
Voltage
14.4V
Working time
About 1 hour
Charging time
About 2.5 hours.（System ON）
About 5 hours. (System OFF）
A.4 Machine Specifications
Main unit dimensions
Maximum dimension:
1776±5mm(H)×550±3mm(W)×828±3mm(D)
Net weight
≤85kg (not including transducer and accessories)
