Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Getting Started
3 Getting Started
3.1 System Configuration
Standard Configuration:
 1 main unit
 1 power cord
 1 potential equalization conductor
 1 bottle of coupling gel
 1 basic user manual and 1 advanced user manual
Options:
 Transducers: L17-7HQ, E8-4Q, C5-2Q, L12-5Q, L17-7SQ, MC8-4Q, P5-1Q, P7-3Q, MC9-
3TQ, C7-2XQ, E10-3BQ, E10-3HQ, C6-2MQ, C5-1Q, L12-5HQ, L12-5WQ, ECL12-3Q, P5-
1XQ
 Needle Guide Bracket Kit
Model
Type
Angle/Depth
Description
BGK-C5-2
In-plane
20°, 28°, 40°
For use with the C7-2XQ,
Supports: 14G-23G
BGK-CR10UA
In-plane
2°
For use with the E8-4Q,
Supports: 16G, 18G
BGK-002
In-plane
38°, 46°, 58°
For use with the L12-5Q/L17-7HQ,
Supports: 14G-23G
BGK-003
Out-of-plane
1.0cm, 1.5cm,
2.0cm
For use with the L12-5Q/L17-7HQ,
Supports: 21G
BGK-004
In-plane
12°, 20°
For use with the MC9-3TQ,
Supports: 14G-23G
BGK-005
In-plane
0°
For use with the E10-3BQ,
Supports: 16G, 18G
BGK-006
In-plane
1°
For use with the E10-3HQ,
Supports: 16G, 18G
BGK-007
In-plane
18°, 25°, 35°
For use with the C5-2Q,
Supports: 14G-23G
BGK-008
In-plane
12° , 22°
For use with the P5-1Q
Supports: 14G-23G
BGK-009
In-plane
14°, 20°, 32°
For use with the C5-1Q
Supports:14G-23G
