Spanning Tree Algorithm

11-18

CLI – This example sets the priority for MSTI 1, and adds VLANs 1-5 to this MSTI.

---------------------------------------------------------------

Eth 1/ 7 information

---------------------------------------------------------------

Admin status: enabled

Role: master

State: forwarding

External admin path cost: 10000

Internal admin path cost: 10000

External oper path cost: 10000

Internal oper path cost: 10000

Priority: 128

Designated cost: 0

Designated port: 128.1

Designated root: 32768.1.0030F1D473A0

Designated bridge: 32768.1.0030F1D473A0

Fast forwarding: disabled

Forward transitions: 1

Admin edge port: disabled

Oper edge port: disabled

Admin Link type: auto

Oper Link type: point-to-point

Spanning Tree Status: enabled

Console(config)#spanning-tree mst-configuration 29-7

Console(config-mst)#mst 1 priority 4096 29-9

Console(config-mstp)#mst 1 vlan 1-5 29-8

Console(config-mst)#
