System Management Commands

19-18

19

Default Setting

None

Command Mode

Global Configuration

Command Usage

• If the file contains an error, it cannot be set as the default file.

Example

Related Commands

dir (19-16)

whichboot (19-17)

Console(config)#boot system config: startup

Console(config)#
