To pump a gas not in the list above, contact the supplier for advice. Failure to contact the
supplier may invalidate the warranty on the pump. The pump is not suitable for pumping
aggressive or corrosive gases.
Venng gas specicaon and vent control data
Although the pump may be vented to atmosphere, high relave humidity of the air may greatly
increase the subsequent pump-down me. To reduce pump-down mes the pump should be
vented with dry, clean gases. Refer to Vent opons, vent valve connecon and control on page
44 for a descripon of the vent opons and the vent valve connecon. Refer to Secon
Controlled venng opons on page 38 for conguring the venng opons.
Table 40
Vent gas specicaon and vent control
Vent gas specicaon and control Reference data
Vent gas Dry air, nitrogen, argon or other inert gases
Maximum dew point at atmospheric pressure -22 °C
Maximum size of parculates 1 μm
Maximum concentraon of oil 0.1 parts per million
Recommended me for rotaonal speed to
reach 50%
> 15 seconds
Maximum allowed rate of pressure rise Refer to Figure 15 on page 89
Maximum allowable vent gas supply pressure 1 bar (gauge); 14.5 psig, 2 x 10
5
Pa
Figure 15
Max allowed rate of pressure rise during venng: pressure against me (pump
inially at full speed)
Materials exposed to gases pumped
The following materials and component types are exposed to the gases pumped:
• aluminium alloys
• steels
• stainless steels
• uoroelastomer and O-rings
B8G0-00-880A - Technical Reference
Page 89
