Edwards nEXT85 User Manual

Figure 10
Accessories
1. TAV Solenoid vent-valve
2. Manual vent-valve (ed)
3. nEXT85 water cooler
4. ACX85 Radial air cooler
5. ACX85 Axial air cooler
6. ACX85 Axial air cooler mounng bracket
7. Base mounng adaptor
8. Inlet screen (CF63 shown)
9. Flange Heater band
Air cooler
The air coolers are available with a pre-wired connector which connects directly to an auxiliary
port on the controller or with a bare wire.
A choice of air coolers can be ed to the pump - refer to Forced air cooling on page 33 to
check the suitability of air cooling in a parcular applicaon. The air coolers are pre-wired to
Vent Opon 2 and the default is set to Always On (opon 8).
Table 24
Air cooler
Item Current draw Item number
nEXT85 Air cooler kit - wired 150 mA B8G200820
nEXT85 Air cooler kit - bare wired 150 mA B8G200821
Water cooler
A water cooler can be ed to the pump if the water supply is suitable..
Refer to Forced air cooling on page 33 to check the suitability of the water cooling supply.
B8G0-00-880A - Accessories for the nEXT85
Page 79
