Edwards nEXT85 - Power Limit Setting; Powering a Fan from the Motor Controller; Table 4 Power Limit Setting

Command ! S
8 5 5
sp
d d d
cr
Typical seng reply:
Reply * S
8 5 5
sp
r
cr
Typical query command:
Command ? S
8 5 5
cr
Typical query reply:
Reply
= S
8 5 5
sp
d d d
cr
Power limit seng
The pump is supplied with a default power limit. If this limit is not suitable for the applicaon,
change it to any value between the maximum and minimum seng.
Table 4
Power limit seng
Maximum value seng Minimum value seng Default power seng
120 W 50 W 80 W
Send the command as follows (where the 'd' characters represent the value in Was that will
be set. For example, to set the limit to 90 W, type 90).
Command
! S
8 5 5
sp
d d d
cr
The reply will be in the following format:
Reply
* S
8 5 5
sp
r
cr
The power limit seng is now stored in memory within the nEXT85 pump. To check what
power limit is set, send a query as follows:
Command
? S
8 5 5
cr
The reply will be in the following format:
Reply
= S
8 5 5
sp
d d d
cr
Powering a fan from the motor controller
A fan can be powered from the nEXT85 motor controller on auxiliary output 2.
Send the following command:
Command
! S
8 6 4
sp
8
cr
The reply will be in the following format:
Reply
* S
8 6 4
sp
r
cr
B8G0-00-880A - Conguraon
Page 37
