Technical Reference

Operang and storage condions

Table 36

Operang and storage condions

Range Data

Ambient operang temperature range 5 °C to 40 °C

Ambient operang humidity range 10 to 90% RH (non-condensing)

Maximum operang altude 2000 m

Ambient storage temperature range -30 °C to 70 °C

General technical data

Table 37

General technical data

General items Reference data

Dimensions Refer to Figure 11 on page 84, Figure 12 on

page 85, Figure 13 on page 85 and Figure

14 on page 85

Maximum inlet ange temperature 120 °C

Polluon degree 61010-1 Polluon degree 2

Maximum external magnec eld 3.5 mT Radial (for standard aluminium

envelope pump)

Equipment type Fixed equipment, for indoor use only

Enclosure protecon (installed) IP64

Power supply 24 - 48 V d.c. (Refer to Electrical data on page

91 for addional informaon)

Figure 11

Dimensions - nEXT85 ISO63

All measurements indicated are shown in mm (inches)

B8G0-00-880A - Technical Reference

Page 84
