Edwards nEXT85 User Manual

0 0 1 0 0 0 1 0 1 0 0 0 0 0 1 1 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0
The following table is provided as an aid.
Table 15
Hexadecimal conversion table
Hexadecimal Binary Decimal
0 0000 0
1 0001 1
2 0010 2
3 0011 3
4 0100 4
5 0101 5
6 0110 6
7 0111 7
8 1000 8
9 1001 9
A 1010 10
B 1011 11
C 1100 12
D 1101 13
E 1110 14
F 1111 15
Each binary digit (bit) represents a ag that is either acve (state 1) or not acve (state 0). To
help decode the system status word, each bit is numbered (starng with 0 for the least
signicant to 31 for the most signicant) as shown below.
Binary digits
0 0 1 0 0 0 1 0 1 0 0 0 0 0 1 1 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0
▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼
3 3 2 2 2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 1 1
9 8 7 6 5 4 3 2 1 0
1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0
Bit numbers
Table 16 on page 71 contains a list of the lower 16 status ags that will be useful for fault
nding. The upper 16 status ags are reserved by Edwards.
Table 16
Status ag
Bit number Status ag Acve ags mean
0 Fail Fail status condion acve
1 Stopped speed Below stopped speed
2 Normal speed Above normal speed
B8G0-00-880A - Troubleshoong
Page 71
