Chapter 4: Supplementary applications
EST3X Technical Reference Manual 93
LED model remote annunciator and expander controls and indicators
Figure 19: LED model remote annunciator and expander controls and indicators
RLED-C
RLED24
Controls Enabled
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
(1)
(1)
(2)
(2)
(3)
(3)
(4)
Note: Item 4 is excluded from the RLED24.
Table 24: LED model remote annunciator and expander controls and indicators
Item Description
Zone description label User-defined zone or device description
Active LED Red LED indicates the zone or device is in alarm state
