EST EST3X - Logic group addresses

Appendix B: Addresses
EST3X Technical Reference Manual 261
Operator layer device address
Table 84 lists the device addresses for points on the EST3X operator layer. See
also Figure 61 on page 262.
Table 84: EST3X operator layer device addresses
Module type
LED or switch Address
12SW/12
LED SW01 to SW12
LED01 to LED12
PPCC0001 to PPCC0012
PPCC0129 to PPCC0140
12SW/24
LED SW01 to SW12
LEDs
PPCC0001 to PPCC0012
PPCC0129 to PPCC0152
24
LED LED01 to LED24 PPCC0129 to PPCC0152
3SW/3
LED×6 Switches
LEDs
PPCC0001 to PPCC0018
PPCC0129 to PPCC0146
3SW/4
LED×4 Switches
LED01
LED02
LED03
LED04
LED05
LED06
LED07
LED08
LED09
LED10
LED11
LED12
PPCC0001 to PPCC0012
PPCC0129
PPCC0131
PPCC0132
PPCC0133
PPCC0135
PPCC0137
PPCC0138
PPCC0139
PPCC0141
PPCC0143
PPCC0144
PPCC0145
