Chapter 5: Installation
EST3X Technical Reference Manual 137
Notes
• For supervised printers, use PT-1S printer model D22300A (120 V) and
PT-1S/220 printer model D22300B (220/240 V).
• If connecting the PT-1S printer to a serial port that is shared with a CDR-3
Bell Coder, refer to “Connecting a CDR-3 for coded tone output” on page 140.
Wiring specifications
• Length: 50 ft (15.2 m) max.
• Resistance: 13 Ω max.
• Wiring: 22 AWG (0.50 mm
2
)
DIP switch settings
Supervised printer
Table 27: Supervised printer DIP switch settings
Switch
1 2 3 4 5 6 7 8
SW1
On On On On On On On On
SW2
On [1] Off [1] On [1] Off Off On On On
[1] Recommended baud rate is 4800 bps
Unsupervised printer
Table 28: Unsupervised printer DIP switch settings
Switch
1 2 3 4 5 6 7 8
SW1
On On On Off On On On On
SW2
On [1] Off [1] On [1] Off Off On On On
[1] Recommended baud rate is 4800 bps
Configuring the printer
1. Configure the printer port using the 3-SDU.
2. Remove the screw from the DIP switch cover on the back of printer. See
Figure 35.
