Chapter 5: Installation
146 EST3X Technical Reference Manual
Switch
Description
S
W1-7 Annunciator circuit type:
Off = Circuit supports Class B and Redundant Class B wiring
On = Circuit supports Class B and Class A wiring
Note: SW1-7 must be set to On.
S
W1-8 Not used
Table 32: Examples of DIP Switch address settings
Address
Setting Address Setting
1
ON
1 2 3 4 5 6 7 8
6
ON
1 2
3 4
5 6
7 8
2
ON
1 2 3 4 5 6 7
8
7
ON
1 2 3 4 5 6 7 8
3
ON
1 2 3 4
5 6 7
8
8
ON
1 2 3 4 5 6 7 8
4
ON
1 2 3 4 5 6 7 8
16
ON
1 2 3 4 5 6 7 8
5
ON
1 2 3 4 5 6 7 8
31
ON
1 2 3 4 5 6 7 8
Runtime errors
Once all the cabinets have been defined, the devices labeled, and rules written in
the 3-SDU the information is compiled. If the compiler finds no errors, the
database is ready to be downloaded to the control panel. If an error occurs
during the download process, it is referred to as a runtime error.
One source of runtime errors occurs during the initial database download. Until
all portions of the database are downloaded into the SFS1-CPU memory, errors
will be generated. Most of these errors will resolve themselves as the system
progresses through download stages.
