Chapter 2: Product description
EST3X Technical Reference Manual 11
Control panel options
Note: Option cards and modules are ordered separately and installed in the field.
Table 3: Control panel option cards
Description
-PS10 Class A Adapter Card: Converts the Class B notification appliance/auxiliary
power circuits on the PS10-4B Power Supply Card to Class A notification
appliance circuits or auxiliary output circuits. Installs on the PS10-4B. See
installation sheet P/N 3101776 for specifications.
-NET8 RS-485 Network Option Card: Provides the interface for both the network
data riser and a digital audio riser. Provides connection to other EST3X
control panels to form an EST3X life safety network (8-node max.). Installs
on the SFS1-CPU. See installation sheet P/N 3101768 for specifications.
-SDC1 Signature loop controller module: Provides a Class B or Class A signaling
line circuit and resettable 24 VDC for powering conventional two-
detector circuits on Signature Series modules. Installs on the SFS1-CPU.
See installation sheet P/N 3101772 for specifications.
-SSDC1 Single Signature loop controller module: Provides one Class B or Class A
Signature data loop for Signature Series detectors and modules. The
module also provides a connection for powering conventional two-wire
smoke detector circuits on Signature Series modules. Installs on the
SFS1-ELEC hardware layer. See installation sheet, P/N 3100584 for
specifications.
-SDDC1 Dual Signature loop controller module: Provides two Class B or Class A
Signature data loops for Signature Series detectors and modules. The
module also provides a connection for powering conventional two-wire
smoke detector circuits on Signature Series modules. Installs on the
SFS1-ELEC hardware layer. See installation sheet P/N 3100584 for
specifications.
-NET RS-485 Network Option Card: Provides the interface for both the network
data riser and a digital audio riser. Provides EST3X
control panel integration
with an EST3 life safety network. Installs on the SFS1-CPU
sheet P/N 3101771 for specifications.
-FIB8 Fiber Optic Network Option Module: Provides a fiber optic or combination
fiber optic and RS-485 communication path for up to eight EST3X control
panels. Installs on the SFS1-CPU and on a half-footprint space on the
CAB6B backbox. See installation sheet, P/N 3101769 for specifications.
-FIB Fiber Optic Network Option Module: Provides a fiber optic or combination
fiber optic and RS-485 communication path for up to 64 EST3X control
panels. The module also provides EST3X control panel integration with an
EST3 life safety network. Installs on the SFS1-CPU and on a half-footprint
space on the CAB6B backbox. See installation sheet, P/N 3101971 for
specifications.
-ETH1
Ethernet Adapter Card: Provides a standard 10/100 BaseT Ethernet network
connection for panel programming and diagnostics. Installs on the
SFS1-CPU. See installation sheet P/N 3101775 for specifications.
