Appendix B: Addresses
260 EST3X Technical Reference Manual
Hardware layer device addresses
Table 83 lists the device addresses for points on the EST3X hardware layer.
Table 83: EST3X hardware layer device addresses
Card
Device or circuit Address
PS10
-4B NAC/AUX 1
NAC /AUX 2
NAC /AUX 3
NAC /AUX 4
PP020001
PP020002
PP020003
PP020004
SFS1
-CPU
Loop 1
Loop 2
Detectors
Modules
Detectors
Modules
PP030001 to PP030125
PP030126 to PP030250
PP030251 to PP030375
PP030376 to PP030500
3
-IDC8/4 IDC/ NAC 1
IDC / NAC 2
IDC 3
IDC 4
IDC / NAC 5
IDC / NAC 6
IDC 7
IDC 8
PPCC0001
PPCC0002
PPCC0003
PPCC0004
PPCC0005
PPCC0006
PPCC0007
PPCC0008
3
-SSDC1 Detectors
Modules
PPCC0001 to PPCC0125
PPCC0126 to PPCC0250
3
-SDDC1
Loop 1
Loop 2
Detectors
Modules
Detectors
Modules
PPCC0001 to PPCC0125
PPCC0126 to PPCC0250
PPCC0251 to PPCC0375
PPCC0376 to PPCC0500
3
-AADC1 Detectors
Modules
PPCC0001 to PPCC0099
PPCC0101 to PPCC0199
3
-ZA20(A/B) Amplifier output
NAC output
PPCC0000
PPCC0001
3
-ZA40(A/B) Amplifier output
NAC output
PPCC0000
PPCC0001
3X
-PMI Default_Normal_PP_08
Default_Alert_PP_08
Default_EVAC_PP_08
Default_Pre_PP_08
MSG_005 to MSG_255
PP080001
PP080002
PP080003
PP080004
PP080005 to PP080255
