Appendix B: Addresses
EST3X Technical Reference Manual 263
Remote annunciator device addresses
Table 85 on page 266 lists the device addresses for LEDs and switches on
RLED-C remote annunciators, RLED24 expanders, GCI graphic annunciator
cards, and GCIX expander cards. See also Figure 62, Figure 63, and Figure 64.
Figure 62: R-LED-C LED numbering
Controls Enabled
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
LED01
LED16
LED17
LED32
LED01
LED16
LED17
LED32
LED33
LED48
RLED-C
RLED24
