Appendix C: Programming options
EST3X Technical Reference Manual 275
Programmable feature
or option
Permitted
in UL 864?
(Y/N)
Possible
settings
Settings
permitted
in UL 864
AND
group member device
types, Activation eve
nt: Q1 -
Alarm
Y GENALARM
SMOKE
SMOKEVFY
HEAT
PULL
STAGEONE
STAGETWO
WATERFLOW
GENALARM
SMOKE
SMOKEVFY [9]
HEAT
PULL
STAGEONE [9]
STAGETWO [9]
WATERFLOW
AND
group device activation
count
Y 1 to 255 1 to 255 [10]
Matrix
group member device
typ
es
Y GENALARM
SMOKE
SMOKEVFY
HEAT
PULL
STAGEONE
STAGETWO
WATERFLOW
GENALARM
SMOKE
SMOKEVFY [8]
HEAT
PULL
STAGEONE [8]
STAGETWO [8]
WATERFLOW
Matrix
groups: Device activation
count
Y 3 to 10 3 to 10 [10]
Signature
input modules:
Personality cod
e 18
N N/A N/A
SIGA
-IO(-MIO) modules:
Personality codes 35 and 36
N N/A N/A
CO Supervisory
N Latching
Nonlatching
N/A
CO Monitor
N Latching Nonlatching N/A
[1] Allowed only when the supervising station supervises the telephone line and annunciates fault
conditions within 200 seconds
[2] Allowed only on control panels that transmit trouble event signals off premises
[3] Allowed only with monitor device types and switches
[4] Allowed only if the user route includes the control panel
[5] Allowed only on nonrequired remote annunciators
[6] Allowed only when setting does not prevent the activation or transmission of alarm or
supervisory signals within 10 seconds or trouble signals within 200 seconds
[7] When priorities are used, alarm events must have a higher priority than supervisory and
trouble events
[8] Not allowed in Zone groups that are used to initiate the release of extinguishing agent or water
[9] Not allowed in AND groups that are used to initiate the release of extinguishing agent or water
[10] A minimum device activation count of 2 is required if the AND group or Matrix group is used
to initiate the release of extinguishing agents or water
