Chapter 3: Operating instructions
EST3X Technical Reference Manual 55
Item
Description
DB S/N
Shows the database serial number (S/N) created when the database was
converted.
Note:
Database serial numbers must match to avoid database incompatibility
faults.
DB Date
Shows the date the database was downloaded.
IP ADDR
Shows the IP address of the control panel.
IP NETWRK
Shows the IP network address of the control panel.
IP GTWY
Shows the IP gateway address of the control panel.
Turning the rotary controller displays information on installed cards, as described
in the table below.
Item
Description
Card
Shows the card address.
ANN Type
Shows the 4X Series Control-Display Module type.
Card Type
Shows the card type. For example, 3-SDDC.
Firmware
Shows the card’s firmware version and date.
Bootstrap
Shows the main SFS1-CPU card’s boot loader and bootstrap version and date
as follows:
• For card address 3, the boot loader version and date
• For card address 4, the bootstrap version and date
Database
Shows the card’s database version and date.
To view the Revisions report:
1. Access the Main Menu, and then click Reports.
2. Click Revisions.
3. Enter the panel address.
4. Click Display and view initial system information. Turn the rotary controller to
view information on installed cards. When finished, click or press the
Acknowledge button to exit the screen.
— or —
Click Print Locally, select the printer, and then click again to exit the screen.
