Multimeter Tests
136 MAX-635G
Isolation
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
Isolation Thresholds
The Isolation Threshold Settings page allows you to
set the Resistance threshold values for each pair. The
threshold is a programmable value you can use as an
on-screen indicator in each test when a measured
value is too high or too low.
 Type is the threshold limit for each pair: either
Maximum or Minimum.
 Enabled is a flag to use the voltage threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
