SmartR™ Features
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 167
FaultMapper
Result displays the cable faults in text and graphical format.
Note: When running FaultMapper with a strap at the far end of the pair, and there
is a T-G/A-E fault, the strap may also cause FaultMapper to display a
R-G/B-E short. In such cases, the resistance shown is the resistance that
would be measured using a multimeter.
Estimated Length displays the cable length when the cable is open.
Note: The cable length may include the Bridge Tap length: remove the Bridge Tap
for better accuracy.
Fault Status displays the number of faults detected (or No fault
detected) after running the test. The status Open detected is reported
in the following case:
No strap.
The pair is open.
No faults (other than the pair being open).
Open and the distance to Open is displayed and represented using X in
the graph.
Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
