Noise Tests
186 MAX-635G
WB PSD Noise
Result displays the following wideband PSD noise test results
differentiating the Current trace from the Peak hold.
Max PSD reading among all frequency bins for the Current results.
Frequency bin where Max PSD for the Current results are
detected.
RMS Noise reading for the Current results including a pass/fail
status.
If Peak Hold is ON:
Max PSD Peak reading among all frequency bins.
Frequency bin for Max PSD Peak.
Test Status displays the current state of measurement or an error
message.
To select the parameter values in Portrait Mode:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
