Hookup Diagram button opens a Confirmation page displaying how
to connect your cables at the beginning of the test. When FED is
Enabled on the FED Setup page, both the T-R/A-B and T1-R1/A1-B1
pairs will be terminated at the FED. The hookup diagram uses graphic
and textual components.
Proceed button closes the hookup diagram prompt and starts the
test.
Cancel button closes the hookup diagram prompt only.
