Frequency Tests
218 MAX-635G
WB Balance
This mode generates the following function keys:
Portrait Mode is used to change the screen orientation from
landscape to portrait.
Select Graph opens a new selection of function keys which allow
you to maneuver the graph. (Same as above.)
Parameters displays a small strip window when selected allowing
you to change the Bandwidth and Termination Resistance values
from a list of options.
To select the parameter values in Landscape Mode:
1. Press the Parameters function key.
2. Press the up/down arrow keys to highlight the desired parameter.
3. Press the left/right arrow keys to view and select the options.
4. Press to confirm the value.
