Frequency Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 247
RX Tone with FED
Result displays the values for both the RX VF/WB Loss and Frequency
Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
Single Tone Result Details
The Result Details read-only page displays the saved
receive tone or VF/WB RX Loss/Frequency values for
the Single RX Tone with FED test.
