TDR
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 269
xTalk TDR
Select Graph button changes to Graph Selected when pressed and
opens a new selection of function keys which allow you to maneuver
the graph as follows:
Cursor/Marker allows you to select the cursor (blue) or marker
(red) independently by toggling the function key. The footer
updates to reflect either Move cursor or Move marker. Press the
left/right arrow keys to decrease/increase the values by moving the
cursor/marker. Press and hold the left/right arrow keys to
accelerate the cursor/marker. Press to recall the cursor/marker
and place it in the middle of the current x-axis limits.
Zoom references the middle of the x/y axis and not the cursor
position. Press the arrow keys as follows:
Right = x-axis zoom in.
Left = x-axis zoom out.
Up = y-axis zoom in.
Down = y-axis zoom out.
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the
previous ones.
Result displays the distance to the most significant reflection, in text
and graphical measurements. The distance (Delta) value between
cursor and marker is also displayed at the top of the graph.
Test Status displays the current state of measurement or an error
message.
Load Trace function key opens a new page that allows you to load a
trace from a list of previously saved TDR tests.
Clear Trace function key deletes the loaded trace from the graph.
