TDR
270 MAX-635G
xTalk TDR
To select the parameter values in Portrait Mode:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view, select the options, or
increase/decrease values.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
Landscape Mode is the best way to use the TDR and allows you to
view the test results in landscape mode utilizing the full length of the
high resolution, color screen. Whether the keyboard is on the right or
left is dependent on your preferred Landscape Mode Settings
configured in Setup/Application Settings/General.
Landscape Mode generates the following function keys:
Portrait Mode is used to change the screen orientation from
landscape to portrait.
Select Graph opens a new selection of function keys which allow
you to maneuver the graph. (Same as above.)
Parameters displays a small strip window listing the following
values: Range and Gain, Pulse Width, and Current Trace. They
can be edited or viewed as described in Portrait Mode (above).
Cable Setup displays a small strip window when selected allowing
you to change the Cable Type, VOP, and Cable Temperature. You
can also view the Cable Fill entry which was setup in Cable Book.
For more information, see Cable Setup in portrait mode.
