Setting Up Copper Tests
82 MAX-635G
Application Settings
VOP Compensation offsets length calculation inaccuracy caused by
the changes in velocity of the pulse propagation, depending on the
pulse width and cable length produced by skin effect; and is applied to
TDR, WB Attenuation, and FaultMapper tests.
Test Startup Mode lists the test startup type:
Auto (default) automatically starts a test when you select the
respective icon from the test sub-menu pane and press .
Manual requires that you press Start/Stop on the MaxTester keypad
to start a test.
Report File Storage Location is dependent on whether Export to
EXFO Connect Client is enabled or not, in System Settings\Upload
Setup. If enabled, you can select either USB or EXFO Connect Client
as your test report storage location. If disabled, USB is automatically
selected.
Report Format is HTML, MHTML, or XML as the generated report
format.
Note: If EXFO Connect Client is selected, the available selections for Report
Format are only MHTML and XML.
Prompt To Save Results allows you to Enable/Disable popup
confirmation messages before leaving a test and not saving results.
Result File Storage Location allows you to select where to save your
results: to a USB or the internal memory of the MaxTester.
