Setting Up Copper Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 83
Application Settings
 Landscape Mode Settings:
 Default Graph Mode sets the default graph viewing mode to either
Portrait or Landscape.
 Screen Rotation sets your preferred default rotation of the unit for
viewing graphs in Landscape mode. Select either Right to rotate
the MaxTester 90 degrees clockwise so that the keypad is on the
left-hand side, or Left to rotate the unit 90 degrees
counter-clockwise so that the keypad is on the right-hand side.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
