Setting Up Copper Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 85
Application Settings
Cable Gauge Unit allows you to select either AWG or mm wire
gauge. AWG is the default for ANSI and mm for ITU. If you select
AWG, only AWG cables will be displayed in the Cable Book\Select
Cable list and test pages.
NTD (Network Terminal Device) Provider allows you to filter out
certain devices in the Pair Detective test dependant on your
provider. None (default) filters out all devices except Short, Phone,
and Phone Off Hook. Disabled does not run the Device Detection
as part of Pair Detective test.
VOP allows you to select the velocity of propagation for the cable
as a Ratio, Percentage, or V/2 m/μsec (meters per microsecond).
Label Customization
Connection lists the type of cable connection: T-R-G or A-B-E.
Test Parameters Preset
Power Line Frequency lists the frequency value of the power line.
Noise Filter lists the type of noise filters to use.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
