CrossPoint / MAV Matrix Switchers • Operation

16-button switchers conﬁguration worksheet

1 2 3 4 5 6 7 8

9 10 11

12 13 14 15 16

10 12 13 14 15 16

Input sources

Output destinations

Preset # Title: Video: Audio:

Fill in the preset number and use colors, or dashes, etc. to make connecting lines.

Indicate if the configuration is for video, audio, or both.
