CrossPoint / MAV Matrix Switchers • Reference Information
B-18
Accessory Part number
MCP1000M(master)matrixcontrolpanel 60-298-01
MCP1000S(slave)matrixcontrolpanel 60-298-02
RCA-BNC adapter 10-264-01
SVHS-BNCadapter 26-353-01
Cables
When using signals with a scanning frequency of 15-125 kHz and running
distancesof100feetormore,usehighresolutionBNCcablestoachievemaximum
performance.
Bulk cable
RG6/super high resolution cable Part number
RG6/SHR-1bulk,500'
22-098-02
RG6/SHR-1bulk,1000' 22-098-03
RG6/SHR-4bulk,500' 22-099-02
RG6/SHR-5bulk,500' 22-100-02
RG6/SHRmalecrimpconnectors,qty.50
100-075-51
RG59/high resolution cable Part number
RG59/HR-1bulk,500' 22-145-02
RG59/HR-1bulk,1000' 22-145-03
RG59/HR-1plenum,bulk,500' 22-146-02
RG59/HR-1plenum,bulk1000' 22-146-03
RG59/HRmalecrimpconnectors,qty.50 100-075-51
BNC-4 mini high resolution cable Part number
BNC-4MiniHRbulk,500' 22-032-02
BNC-4MiniHRbulk,1000' 22-032-03
BNC-5 mini high resolution cable Part number
BNC-5MiniHRbulk,500' 22-020-02
BNC-5MiniHRbulk,1000' 22-020-03
Plenum BNC-5 mini high resolution cable Part number
PlenumBNC-5MiniHRbulk,500' 22-103-02
PlenumBNC-5MiniHRbulk,1000' 22-103-03
N
Bulk cable in lengths up to 5000’ (1524 meter) rolls is available with or without
connectors.
